Detailed Description

Represents the configuration interface for mirrored input ports.

Allows listing available streaming sources and selecting the active source for a mirrored input port. Only sources that support client-to-device streaming are allowed. The active sources sends client signal (and the associated domain signal) data to the device, which is then consumed by the connection formed by the input port origin and the mirrored signal connected to it.

Public Member Functions
daq::StringPtr	getRemoteId () const
	Gets the global ID of the input port as it appears on the remote device. More...

daq::ListPtr< daq::IString >	getStreamingSources () const
	Gets a list of connection strings of all available streaming sources of the input port. More...

void	setActiveStreamingSource (const daq::StringPtr &streamingConnectionString) const
	Sets the active streaming source of the input port. More...

daq::StringPtr	getActiveStreamingSource () const
	Gets a connection strings of the active streaming source of the input port. More...

Public Member Functions inherited from GenericInputPortPtr< IMirroredInputPortConfig >
daq::Bool	acceptsSignal (const daq::SignalPtr &signal) const
	Returns true if the signal can be connected to the input port; false otherwise. More...

void	connect (const daq::SignalPtr &signal) const
	Connects the signal to the input port, forming a Connection. More...

void	disconnect () const
	Disconnects the signal from the input port.

daq::SignalPtr	getSignal () const
	Gets the signal connected to the input port. More...

daq::Bool	getRequiresSignal () const
	Returns true if the input port requires a signal to be connected; false otherwise. More...

daq::ConnectionPtr	getConnection () const
	Gets the Connection object formed between the Signal and Input port. More...

daq::Bool	getPublic () const
	Returns true if the port is public; false otherwise. More...

void	setPublic (daq::Bool isPublic) const
	Sets the port to be either public or private. More...

daq::ListPtr< daq::IBoolean >	acceptsSignals (const daq::ListPtr< daq::ISignal > &signals) const
	Checks whether the given signals can be connected to the input port. More...

Public Member Functions inherited from GenericComponentPtr< IMirroredInputPortConfig >
daq::StringPtr	getLocalId () const
	Gets the local ID of the component. More...

daq::StringPtr	getGlobalId () const
	Gets the global ID of the component. More...

daq::Bool	getActive () const
	Returns true if the component is active; false otherwise. More...

void	setActive (daq::Bool active) const
	Sets the component to be either active or inactive. Sets the local active state and notifies children about the parent active state change. More...

daq::ContextPtr	getContext () const
	Gets the context object. More...

daq::ComponentPtr	getParent () const
	Gets the parent of the component. More...

daq::StringPtr	getName () const
	Gets the name of the component. More...

void	setName (const daq::StringPtr &name) const
	Sets the name of the component. More...

daq::StringPtr	getDescription () const
	Gets the description of the component. More...

void	setDescription (const daq::StringPtr &description) const
	Sets the description of the component. More...

daq::TagsPtr	getTags () const
	Gets the tags of the component. More...

daq::Bool	getVisible () const
	Gets `visible` metadata state of the component. More...

void	setVisible (daq::Bool visible) const
	Sets `visible` attribute state of the component. More...

daq::ListPtr< daq::IString >	getLockedAttributes () const
	Gets a list of the component's locked attributes. The locked attributes cannot be modified via their respective setters. More...

daq::Event< daq::ComponentPtr, daq::CoreEventArgsPtr >	getOnComponentCoreEvent () const
	Gets the Core Event object that triggers whenever a change to this component happens within the openDAQ core structure. More...

daq::ComponentStatusContainerPtr	getStatusContainer () const
	Gets the container of Component statuses. More...

daq::ComponentPtr	findComponent (const daq::StringPtr &id) const
	Finds the component (signal/device/function block) with the specified (global) id. More...

daq::OperationModeType	getOperationMode () const
	Gets the operation mode of the device. More...

daq::Bool	getLocalActive () const
	Returns true if the component is local active; false otherwise. More...

daq::Bool	getParentActive () const
	Returns true if the component's parent is active; false otherwise. More...

Public Member Functions inherited from GenericPropertyObjectPtr< IMirroredInputPortConfig >
daq::StringPtr	getClassName () const
	Gets the name of the class the Property object was constructed with. More...

void	setPropertyValue (const daq::StringPtr &propertyName, const daq::BaseObjectPtr &value) const
	Sets the value of the Property with the given name. More...

daq::BaseObjectPtr	getPropertyValue (const daq::StringPtr &propertyName) const
	Gets the value of the Property with the given name. More...

daq::BaseObjectPtr	getPropertySelectionValue (const daq::StringPtr &propertyName) const
	Gets the selected value of the Property, if the Property is a Selection property. More...

void	clearPropertyValue (const daq::StringPtr &propertyName) const
	Clears the Property value from the Property object. More...

daq::Bool	hasProperty (const daq::StringPtr &propertyName) const
	Checks if the Property object contains a property named `propertyName`. More...

daq::PropertyPtr	getProperty (const daq::StringPtr &propertyName) const
	Gets the Property with the given `propertyName`. More...

void	addProperty (const daq::PropertyPtr &property) const
	Adds the property to the Property object. More...

void	removeProperty (const daq::StringPtr &propertyName) const
	Removes the Property named `propertyName` from the Property object. More...

daq::Event< daq::PropertyObjectPtr, daq::PropertyValueEventArgsPtr >	getOnPropertyValueWrite (const daq::StringPtr &propertyName) const
	Gets the Event that is triggered whenever a Property value is written to the Property named `propertyName`. More...

daq::Event< daq::PropertyObjectPtr, daq::PropertyValueEventArgsPtr >	getOnPropertyValueRead (const daq::StringPtr &propertyName) const
	Gets the Event that is triggered whenever a Property value of a Property named `propertyName` is read. More...

daq::Event< daq::PropertyObjectPtr, daq::PropertyValueEventArgsPtr >	getOnAnyPropertyValueWrite () const
	Gets the Event that is triggered whenever any Property value is written. The event is triggered after the specific Property event. More...

daq::Event< daq::PropertyObjectPtr, daq::PropertyValueEventArgsPtr >	getOnAnyPropertyValueRead () const
	Gets the Event that is triggered whenever any Property value is read.The event is triggered after the specific Property event. More...

daq::ListPtr< daq::IProperty >	getVisibleProperties () const
	Returns a list of visible properties contained in the Property object. More...

daq::ListPtr< daq::IProperty >	getAllProperties () const
	Returns a list of all properties contained in the Property object. More...

void	setPropertyOrder (const daq::ListPtr< daq::IString > &orderedPropertyNames) const
	Sets a custom order of properties as defined in the list of property names. More...

void	beginUpdate () const
	Begins batch configuration of the object. More...

void	endUpdate () const
	Ends batch configuration of the object. More...

daq::Bool	getUpdating () const
	Returns the state of batch configuration. More...

daq::Event< daq::PropertyObjectPtr, daq::EndUpdateEventArgsPtr >	getOnEndUpdate () const
	Gets the Event that is triggered whenever the batch configuration is applied. More...

daq::PermissionManagerPtr	getPermissionManager () const
	Gets the permission manager of property object. More...

daq::ListPtr< daq::IProperty >	findProperties (const daq::SearchFilterPtr &propertyFilter, const daq::SearchFilterPtr &componentFilter=nullptr) const
	Retrieves a list of properties from the Property object that match the given property filter. More...

void	setPropertySelectionValue (const daq::StringPtr &propertyName, const daq::BaseObjectPtr &value) const
	Sets the value of a Selection property by the selection item value (e.g. string, float, or list/dict value). More...

void	clearPropertyValues () const
	Clears values of all properties contained in the Property object, including nested child properties. More...

Member Function Documentation

◆ getActiveStreamingSource()

daq::StringPtr getActiveStreamingSource ( ) const

inline

Gets a connection strings of the active streaming source of the input port.

Returns: The connection string of active streaming source.

◆ getRemoteId()

daq::StringPtr getRemoteId ( ) const

inline

Gets the global ID of the input port as it appears on the remote device.

Returns: The input port ID.

◆ getStreamingSources()

daq::ListPtr< daq::IString > getStreamingSources ( ) const

inline

Gets a list of connection strings of all available streaming sources of the input port.

Returns: The list of streaming connection strings.

◆ setActiveStreamingSource()

void setActiveStreamingSource ( const daq::StringPtr & streamingConnectionString ) const

inline

Sets the active streaming source of the input port.

Parameters

streamingConnectionString The connection string of streaming source to be set as active.

Exceptions

NotFoundException if the streaming source with the corresponding connection string is not * part of the available streaming sources for the input port.
