Container of properties that can be used as a base class when instantiating a Property object. More...

Inheritance diagram for PropertyObjectClassPtr:

Collaboration diagram for PropertyObjectClassPtr:

Detailed Description

Container of properties that can be used as a base class when instantiating a Property object.

A Property object class is defined via a name and a list of properties. For a Property object to be created, using a class as its base, a class must be added to the Type manager.

The name of the class must be unique within a given Type manager instance. The name of the Class is used when choosing a template class for a Property object, as well as to define a class hierarchy. A class with the Parent name configured will inherit the properties of the class with said name.

The properties of a Property object class are, by default, sorted in insertion order. The order can, however, be overridden by specifying a Property object order - a list containing the names of properties. If specified, when retrieving the list of properties, they will be in the provided order.

All Property object class objects are created as Property object class builder objects that allow for customization and building of the class.

Public Member Functions
daq::StringPtr	getParentName () const
	Gets the name of the parent of the property class. More...

daq::PropertyPtr	getProperty (const daq::StringPtr &propertyName) const
	Gets the class's property with the given name. More...

daq::Bool	hasProperty (const daq::StringPtr &propertyName) const
	Checks if the property is registered. More...

daq::ListPtr< daq::IProperty >	getProperties (daq::Bool includeInherited) const
	Gets the list of properties added to the class. More...

Public Member Functions inherited from GenericTypePtr< IPropertyObjectClass >
StringPtr	getName () const
	Gets the name of the Type. More...

Public Member Functions inherited from ObjectPtr< IPropertyObjectClass >
	ObjectPtr ()
	Creates a smart pointer with no wrapped interface.

	ObjectPtr (std::nullptr_t)
	Creates a smart pointer with no wrapped interface.

	ObjectPtr (const ObjectPtr< IPropertyObjectClass > &objPtr)
	Creates a smart pointer from another smart pointer. More...

	ObjectPtr (ObjectPtr< IPropertyObjectClass > &&objPtr) noexcept
	Creates a smart pointer from another smart pointer with move semantics. More...

	ObjectPtr (const ObjectPtr< U > &objPtr)
	Creates a smart pointer from another smart pointer of a different interface type. More...

	ObjectPtr (ObjectPtr< U > &&objPtr)
	Creates a smart pointer from another smart pointer of a different interface type with move semantics. More...

	ObjectPtr (IPropertyObjectClass *&obj)
	Creates a smart pointer from an interface pointer. More...

	ObjectPtr (IPropertyObjectClass *&&obj)
	Creates a smart pointer from an interface pointer with move semantics. More...

	ObjectPtr (IWeakRef *obj)
	Creates a smart pointer from a weak reference interface pointer. More...

	ObjectPtr (const wchar_t *value)
	Creates a string object smart pointer from UTF16 null terminated sequence. More...

	ObjectPtr (ConstCharPtr value)
	Creates a string object smart pointer from UTF8 null terminated sequence. More...

	ObjectPtr (const U &value)
	Creates a smart pointer wrapper from value type. More...

virtual	~ObjectPtr ()
	Destructor. More...

bool	equals (ObjectPtr< IBaseObject > other) const
	Compares object to another object for equality. More...

IPropertyObjectClass *	detach ()
	Disassociates this smart pointer object from the interface that it represents. More...

void	dispose () const
	Disposes all references held by the object. More...

void	release ()
	Resets the wrapped interface to nullptr. More...

IPropertyObjectClass *	addRefAndReturn () const
	Increments the reference count and returns the interface. More...

	operator IPropertyObjectClass * () const
	Casts the pointer to the wrapped interface. More...

bool	assigned () const
	Checks if the smart pointer is not empty.

IPropertyObjectClass *	getObject () const
	Gets the pointer to the wrapped interface. More...

IPropertyObjectClass **	addressOf ()
	Gets the address of the pointer to the wrapped interface. More...

IPropertyObjectClass **	operator& ()
	Gets the address of the pointer to the wrapped interface. More...

U *	as (bool borrow=false) const
	Casts the wrapped interface to another interface. More...

U *	asOrNull (bool borrow=false) const
	Casts the wrapped interface to another interface. More...

Ptr	asPtr (bool borrow=false) const
	Casts the wrapped interface to another interface and wraps in a smart pointer. More...

Ptr	asPtrOrNull (bool borrow=false) const
	Casts the wrapped interface to another interface and wraps in a smart pointer. More...

bool	supportsInterface () const
	Checks if the wrapped interface supports another interface. More...

bool	supportsInterface (const IntfID &id) const
	Checks if the wrapped interface supports another interface using the interface ID. More...

CoreType	getCoreType () const
	Gets the object's `CoreType`. More...

ObjectPtr< IBaseObject >	convertTo (CoreType ct) const
	Converts the object to the specified `CoreType`. More...

SizeT	getHashCode () const
	Returns hash code of the object. More...

ObjectPtr< IString >	toString () const
	Converts the object to the string object. More...

void	freeze () const
	Freezes the object. More...

Bool	isFrozen () const
	Checks if the object is frozen. More...

void	dispatch (const ObjectPtr< IBaseObject > &params) const
	Calls the stored callback. More...

void	dispatch () const
	Calls the stored callback without any parameters. More...

void	execute () const
	Calls the stored callback without any parameters. More...

void	execute (Params... params) const
	Calls the stored callback. More...

ObjectPtr< IBaseObject >	call (Params... params) const
	Calls the stored callback and returns the result. More...

bool	isBorrowed () const
	Checks if the reference is borrowed. More...

Additional Inherited Members
Static Public Member Functions inherited from ObjectPtr< IPropertyObjectClass >
static InterfaceToSmartPtr< U >::SmartPtr	Borrow (IPropertyObjectClass *&obj)
	Borrows an interface. More...

static InterfaceToSmartPtr< V >::SmartPtr	Borrow (U *&obj)
	Borrows an interface from the interface of another type. More...

static InterfaceToSmartPtr< U >::SmartPtr	Adopt (IPropertyObjectClass *obj)
	Adopts an interface. More...

static Bool	Equals (const ObjectPtr< IBaseObject > &a, const ObjectPtr< IBaseObject > &b)
	Value based comparison of two objects. If both objects are nullptr, they are considered to be equal. More...

Member Function Documentation

◆ getParentName()

daq::StringPtr getParentName ( ) const

inline

Gets the name of the parent of the property class.

Returns: The parent class's name.

◆ getProperties()

daq::ListPtr< daq::IProperty > getProperties ( daq::Bool includeInherited ) const

inline

Gets the list of properties added to the class.

Parameters

includeInherited If true, the returned list of properties also includes the properties of the class's ancestors.

Returns: The list of properties.

Exceptions

OpendaqErrException if the parent name is set, but the Type manager is not available.

The properties are sorted in insertion order, unless a custom sorting order is specified for the class. Any properties not listed in the custom sorting order are listed at the end of the properties list, sorted in insertion order.

◆ getProperty()

daq::PropertyPtr getProperty ( const daq::StringPtr & propertyName ) const

inline

Gets the class's property with the given name.

Parameters

propertyName The property's name.

Returns: The property.

Exceptions

NotFoundException	if the Property with name `propertyName` is not added to the class.
OpendaqErrException	if the parent name is set, but the Type manager is not available.

◆ hasProperty()

daq::Bool hasProperty ( const daq::StringPtr & propertyName ) const

inline

Checks if the property is registered.

Parameters

propertyName The property's name.

Returns: True if the property is registered, false otherwise.

Exceptions

OpendaqErrException if the parent name is set, but the Type manager is not available.
